C3-H9047 USB-C to 3-Port USB 3.0 and Gigabit Ethernet Hub
USB-C to 3-Port USB 3.0 and Gigabit Ethernet Hub
Introduction:
C3-H9047 quickly added a Gigabit Ethernet port over new USB-C standard. It provides extra connectivity from your computer with 5Gbps faster transfer speed. It allows you to add three USB 3.0 peripherals and one Gigabit LAN (10/100/1000Mbps) via the attached USB-C Upstream cable.
Feature:
- USB 3.0 SuperSpeed Hub
‧ Provides three USB 3.0 SuperSpeed ports
‧ Transfer rates up to 5Gb/s, enabling bulky file backup
‧ Compliant to USB 3.0 specification and backward compatible to USB 2.0 and USB 1.1 device
‧ Plug & Play - USB 3.0 Gigabit Ethernet
‧ Quickly add a Gigabit Ethernet port over USB-C
‧ Transfer all of your files almost instantly over a true Gigabit network.
‧ IEEE 802.3, 802.3u and 802.3ab (1BASE-T, 100BASE-TX, and 1000BASE-T) compliant
‧ Activity and Link LED indicators
Specification:
| Interface | |
|
Chipset |
#AX88179 & GL3522 |
|
Host Interface |
USB-C connector |
|
Cable Length |
10±1 cm (Type C Male to 9pin cable, soldered on PCBA) |
|
LAN Interface |
RJ45 female connector (Gigabit Ethernet) |
|
USB Interface |
USB 3.0 female connector x 3 |
|
Power Jack |
DC 5V (3.5mm) |
|
Power Source |
Bus Powered and/or Self-Powered |
|
Power Adapter |
5V/2A power adapter (optional) |
|
Working Current |
≦300 mA +/- 10mA |
| Environmental | |
|
Storage Temperature |
-10 – 65°C |
|
Storage Humidity |
< 85% non-condensing |
|
Operation Temperature |
0 – 50°C |
|
Operation Humidity |
< 85% non-condensing |
OS Support:
- Windows 7/ 8/ 8.1/10
- Mac OS 10.6 and later
- Chrome OS
System Requirements:
- CPU: Intel 2 core Quad 2.33 GHz
- RAM: 2 GB DDR2
- Available USB Type-C port
Package Contents:
- USB-C to 3-Port USB 3.0 and Gigabit Ethernet Hub
- Quick Installation Guide
